Energy Recovery System

An energy recovery system in HVAC is designed to reclaim energy from exhaust air and reuse it to pre-condition incoming fresh air. This reduces the energy needed for heating or cooling, making HVAC systems more efficient and environmentally friendly. Incorporating an energy recovery system is crucial for businesses aiming to reduce operational costs while maintaining a sustainable approach to climate control.

What is an Energy Recovery System?

An energy recovery system in HVAC is a technology that recaptures energy from exhausted air, transferring it to incoming air to improve efficiency. This allows HVAC systems to operate more effectively, lowering energy demands while maintaining indoor comfort levels. These systems work by moving heat or cooling energy between two airflows, either to pre-cool or pre-heat the fresh air entering the building.

Types of Energy Recovery Systems

There are several energy recovery systems available, each suited to different HVAC needs and building environments:

Energy Recovery Wheel

• Energy recovery wheel - Also known as an enthalpy wheel or rotary heat exchanger, the energy recovery wheel rotates between the exhaust and incoming air streams, capturing both heat and moisture. This makes it particularly effective in climates where humidity control is essential, as it can transfer both sensible and latent energy. The wheel’s effectiveness makes it a popular choice for commercial buildings seeking to reduce energy costs associated with both temperature and humidity control.

Plate Heat Exchangers

• Plate heat exchangers - Consist of parallel plates that separate the two air streams while allowing thermal energy to pass through. These systems are effective in capturing sensible heat, making them suitable for environments where minimizing energy transfer while avoiding cross-contamination is critical. Plate heat exchangers are often used in facilities like hospitals, where maintaining air purity is essential.

Heat Pipes

• Heat pipes - Use sealed pipes filled with a refrigerant fluid that absorbs heat from one airstream and transfers it to another. The heat pipe's simplicity and effectiveness in transferring sensible heat make it a great solution for environments that prioritize low maintenance. Heat pipes are frequently used in data centers and other environments where consistent temperature control is needed, without the need for complex equipment.

Run-Around Coils

• Run-around coils - Utilize two separate coils connected by a pumped water or glycol loop. One coil is placed in the exhaust stream, while the other is in the fresh air stream. The fluid transfers the heat energy between the two coils. This type of system is ideal for facilities needing strict separation between air streams, such as pharmaceutical manufacturing facilities or labs, as there is no direct mixing of air.

Fixed Plate Energy Recovery Units

• Fixed plate units - Use solid plates that transfer heat between incoming and outgoing air streams without any moving parts. These units are advantageous because of their simple design, reliability, and minimal maintenance needs. Fixed plate energy recovery units are typically used in small commercial buildings or residential complexes where straightforward, efficient heat exchange is required.

Benefits of Energy Recovery Systems in HVAC

Incorporating an energy recovery system into an HVAC setup provides numerous advantages:

• Energy Efficiency - By capturing energy from exhaust air, these systems reduce the workload on HVAC units, significantly lowering energy consumption.
• Cost Reduction - Lower energy usage translates to lower energy bills, making these systems a cost-effective addition to HVAC solutions.
• Environmental Impact - Reducing energy consumption decreases carbon emissions, contributing to a more sustainable and eco-friendly operation.
• Improved Indoor Comfort - Energy recovery systems help maintain balanced temperatures and humidity levels, which enhances the comfort of building occupants, particularly in climates with significant seasonal changes.

Energy Recovery Units for HVAC Applications

Energy recovery units are integral to various HVAC applications across different types of facilities:

• Office Buildings - Energy recovery units reduce the load on HVAC systems in commercial buildings by pre-conditioning fresh air, which improves comfort levels and reduces operational costs.
• Hospitals and Laboratories - Critical environments like medical facilities where air quality and energy efficiency are vital. Energy recovery ensures the proper conditioning of incoming air while keeping contaminants from the exhaust air out.
• Educational Facilities - Schools and universities benefit from consistent indoor air quality while keeping energy usage and costs manageable.
• Industrial Facilities - Industrial areas requiring large ventilation capacities can achieve significant energy savings by integrating energy recovery systems to pre-condition outside air.
