Energy Recovery Systems in Air Handling Units: Save Energy & Costs

With rising energy costs and a global focus on sustainable practices, businesses and property owners are increasingly looking for ways to improve the efficiency of their HVAC systems. One of the most effective methods is incorporating energy recovery systems (ERS) into air handling units (AHUs). These systems help reduce energy consumption by reusing the energy from exhaust air, resulting in significant cost savings and environmental benefits. This article explores the role of energy recovery systems in AHUs, their types, benefits, and how they contribute to energy efficiency.

Enegry recovery systems - air handling unit manufacturers

What is an Energy Recovery System?

An Energy Recovery System (ERS) is designed to transfer energy between the exhaust air leaving a building and the fresh air entering it. By capturing heat or cooling from the outgoing air, the system reduces the amount of energy needed to condition the incoming air. This process minimizes the workload on HVAC components like heating and cooling coils, making the entire air handling unit system more efficient.

How Energy Recovery Systems Work in AHUs

When a building’s AHU brings in fresh outdoor air, that air must be cooled, heated, or dehumidified to maintain comfortable indoor conditions. Without an energy recovery system, the energy used to condition the exhaust air would be lost. ERS captures that otherwise wasted energy and uses it to pre-condition the incoming air. This process works year-round, whether in winter (recovering heat) or summer (recovering cooling).

Types of Energy Recovery Systems for AHUs

  1. Heat Wheels (Rotary Heat Exchangers)
    A rotating wheel made of heat-conductive material transfers energy between the exhaust and supply air streams. These are highly efficient and can recover both heat and humidity.

    Best for: Large commercial or industrial buildings requiring high airflow rates.

  2. Plate Heat Exchangers
    Two air streams pass over thin metal plates, allowing heat to transfer between them without mixing. They are simple, maintenance-friendly systems but cannot recover humidity.

    Best for: Hospitals, offices, and areas with strict air quality standards.

  3. Heat Pipes
    Sealed tubes filled with refrigerant transfer heat between exhaust and intake air. Heat pipes are durable and offer good efficiency but are only useful for sensible (temperature) heat recovery.

    Best for: Hot climates where cooling energy recovery is a priority.

  4. Run-Around Coils
    A liquid-filled coil captures heat from the exhaust air and transfers it to the supply air through a separate coil. While not as efficient as heat wheels, they offer flexibility for complex duct configurations.

    Best for: Facilities with widely separated airflows or challenging layouts.

Benefits of Energy Recovery Systems in AHUs

  1. Significant Energy Savings
    By recycling energy from exhaust air, ERS reduces the workload on HVAC systems. This leads to lower electricity and fuel consumption, especially in buildings with high ventilation needs.

    Example: A commercial building equipped with an energy recovery wheel can reduce its HVAC energy consumption by up to 50%, resulting in thousands of dollars saved annually.

  2. Improved Indoor Air Quality (IAQ)
    Energy recovery systems allow buildings to bring in more fresh air without increasing energy costs, improving air quality and reducing the risk of pollutants building up indoors.

  3. Extended Equipment Life
    With ERS taking on part of the load, HVAC components like compressors and heating coils experience less strain. This reduces wear and tear, lowering maintenance costs and extending equipment lifespan.

  4. Environmental Benefits
    Lower energy consumption means fewer greenhouse gas emissions. This aligns with sustainability goals and helps businesses meet regulatory standards for energy efficiency.

Applications of Energy Recovery Systems in AHUs

  • Commercial Buildings: Offices, schools, and shopping malls benefit from energy recovery systems by reducing heating and cooling costs, especially in large spaces with high ventilation demands.
  • Healthcare Facilities: Hospitals and clinics require strict ventilation to ensure air quality. ERS helps maintain these standards while keeping energy use in check.
  • Industrial Settings: Factories and warehouses with high ventilation rates can significantly reduce operational costs with energy recovery systems.
  • Residential Developments: In multi-family housing and high-rise apartments, ERS ensures energy-efficient ventilation, improving comfort while controlling utility costs.

Challenges and Solutions in Implementing Energy Recovery Systems

  1. Initial Investment Costs
    While installing energy recovery systems requires upfront investment, the long-term savings in energy costs often offset these expenses within a few years. Government rebates and incentives are also available to ease the financial burden.

  2. Space and Ductwork Constraints
    Retrofitting older buildings with energy recovery systems can be challenging due to space limitations. In such cases, compact options like heat pipes or run-around coils may offer the best solution.

  3. Maintenance Requirements
    Regular maintenance is essential to keep ERS functioning efficiently. However, most systems—such as plate heat exchangers—are easy to maintain with periodic cleaning.

Global and South African Perspectives

Globally, energy recovery systems are becoming a standard feature in modern HVAC systems as governments push for stricter energy efficiency standards. The European Union’s Energy Performance of Buildings Directive (EPBD) requires energy recovery in new constructions, making ERS a common practice across Europe.

In South Africa, with rising energy costs and ongoing challenges like load-shedding, businesses are increasingly looking at ways to reduce dependence on the grid. Incorporating energy recovery systems into air handling units offers a practical solution to save energy, reduce operational costs, and meet sustainability goals. Programs such as the South African National Energy Development Institute (SANEDI) encourage the adoption of energy-efficient technologies, including HVAC upgrades, making ERS an attractive option for both commercial and residential buildings.

Air Options - Air Handling Unit Manufacturers

Integrating an energy recovery system into your air handling unit is a practical way to reduce energy consumption, improve air quality, and lower operational costs. Whether for a commercial office, healthcare facility, or residential development, these systems offer a reliable way to maximise HVAC efficiency. In a world where energy efficiency is no longer a luxury but a necessity, energy recovery systems represent a smart investment with long-lasting benefits.

For property owners and facility managers in South Africa and beyond, adopting energy-efficient technologies like ERS helps future-proof buildings against rising energy costs and environmental regulations. Whether you are considering an upgrade or planning a new installation, energy recovery systems will enhance your air handling unit’s performance and offer financial savings for years to come.
